6-Light LED Fog Pocket Kit for Ford F-150 Raptor 2021–2026

Set your Ford F-150 Raptor apart with the Baja Designs fog pocket kit featuring two Squadron 2.0 Sport, two Squadron SAE and two S1 lights. It’s the ideal solution for those who want powerful off-road lighting combined with street-legal fog lights.

The kit uses two Squadron 2.0 Sport, two Squadron SAE and two S1 LED lights for excellent illumination on tough terrain.

The new-generation Squadron 2.0 Sport uses advanced optics and delivers 3,200 lumens at 30 W per light – 26% more output than the previous generation, plus improved control and higher efficiency.

The updated Squadron 2.0 Sport design includes optimized lenses, a rugged 4-pin connector and RGBW backlighting with 9 selectable colors, letting you match the lights to the style of your Raptor. The improved service system uses locking reflectors for easy, secure lens changes, and the new seal provides better weather protection.

Squadron SAE uses aspheric projector optics and advanced LED technology, delivering 2,420 lumens per light at 29 W and up to 15,800 candela. Designed to current SAE J583 requirements, it is approved for on-road use. The controlled beam with a sharp cutoff is suited to driving in fog, dust, rain and other adverse weather conditions.

The two S1 lights complete the system with 2,320 lumens per light each, providing additional wide terrain illumination.

The kit contains everything needed for installation and includes vehicle-specific mounting brackets and wiring harnesses that allow the factory switches to be used.

Backed by a 30-day satisfaction guarantee and a limited lifetime warranty, this kit offers powerful, reliable lighting for every adventure.

Squadron 2.0 Sport features

• Improved beam pattern for greater distance and wider coverage
• Reduced unwanted light scatter
• RGBW backlight with 9 selectable colors
• Locking reflectors for easier lens changes
• New seal for better weather protection
• Mounting brackets with improved vertical adjustment
• Standard 4-pin connector for more durable wiring connections

What’s in the Box

• 2x S1 – Wide Cornering, clear lens
• 2x Squadron 2.0 Sport – Driving Combo, clear lens
• 2x Squadron 2.0 Sport – Spot, clear lens
• 2x mounting brackets
• 2x adapter cables
• 1x splitter for 2 lights
• 2x 55″ splitter cables
• 1x wiring harness for the factory switches
• All necessary mounting hardware

Technical Specifications

Squadron 2.0 Sport – per light:

• Light output: 3,200 lumens
• Power: 30 W
• Current draw: 2,2 A

Squadron SAE – per light:

• Light output: 2,420 lumens
• Power: 29 W
• Current draw: 2,1 A

S1 – per light:

• Light output: 2,320 lumens
• Power: 20 W
• Current draw: 1,42 A

Baja Designs advantages

• 30-day satisfaction guarantee
• Limited lifetime warranty
• Service system – replaceable lenses and optics
• Optimized light distribution
• Moisture protection – waterproof, rain- and submersion-resistant
• Direct heat sinking
• 5000K daylight – less driver fatigue and natural color perception

Fits

• Ford F-150 Raptor 2021–2026
